The 1.0-2.3 connector series was originally launched by the European Telecommunications Market in the 1990s. Compact design allows dense connector packaging, which is an ideal solution for applications with space constraints. It has 50 Ξ© and 75 Ξ© impedance for choice and is compatible with the most widely used cable sizes. The push/pull lock and release feature makes it really easy to use.
| RF Series | DIN 1.0/2.3 |
|---|---|
| Connector Type | Plug |
| Orientation | Straight |
| Contact Type | Male Pin |
| Contact Termination Style | |
| Shield Termination | |
| Mounting Type | |
| Cable Type | |
| Number of Ports | |
| Body Material | |
| Body Plating | Nickel Plating |
| Insulator Material | PTFE |
| Contact Material | Brass |
| Contact Plating | Gold Plating |
| Fastening Type | Push-Pull |
|---|---|
| Mating Durability | β₯ 500 Cycles |
| Impedance | 75 Ξ© |
|---|---|
| Rated Voltage | 250 Volts RMS Max Continuous |
| Dielectric Withstanding Voltage | 750 VRMS Max |
| Insultation Resistance | 10000 M⦠Min |
| Frequency Range | DC – 10 GHz for 50 ohm, DC – 3 GHz for 75 ohm |
| Temperature Range | β65Β°C to +165Β°C |
|---|
| RF Series | DIN 1.0/2.3 |
|---|---|
| Connector Type | Plug |
| Orientation | Straight |
| Contact Type | Male Pin |
| Contact Termination Style | |
| Shield Termination | |
| Mounting Type | |
| Cable Type | |
| Fastening Type | Push-Pull |
| Number of Ports | |
| Impedance | 75 Ξ© |
| Body Material | |
| Body Plating | Nickel Plating |
| Insulator Material | PTFE |
| Contact Material | Brass |
| Contact Plating | Gold Plating |
| Rated Voltage | 250 Volts RMS Max Continuous |
| Dielectric Withstanding Voltage | 750 VRMS Max |
| Insultation Resistance | 10000 M⦠Min |
| Temperature Range | β65Β°C to +165Β°C |
| Mating Durability | β₯ 500 Cycles |
| Frequency Range | DC – 10 GHz for 50 ohm, DC – 3 GHz for 75 ohm |
