The intermodulation distortion of rf passive devices is caused by the non-source intermodulation (PIM) due to its nonlinear characteristics, and this is also the case with connectors.

There are many reasons for the non-linearity of rf connectors or cable assemblies. For example, the contact of the conductor is bad, the surface coating is uneven, the surface of the metal is oxidized, and the surface of the contact surface is impurities and surface corrosion. In addition, magnetic materials such as nickel and steel produce nonlinear factors.

Integration of inner conductor and outer conductor welding structure, so that we can guarantee the rf connector low tonal, also can avoid due to wind, vibration, and heat bilges cold shrink effect produced by the poor contact. The surface coating of the connector is also very important. The inner conductor can be plated with gold or silver plating, and the outer conductor can be plated with silver or ternary alloy to ensure the passive intermodulation index.

From the 1960s, China began to manufacture the RF connectors with the machine factory. In the 70s, it produced by professional manufacturer. Before the 80s, according to the principle self-reliance, our products were based on imitation of Soviet products. Since the 1980s, international standards have been adopted to produce the international series products, Mainly state-owned and collective enterprises, a number of private, joint ventures and foreign enterprises. At present, there are several hundred RF connector manufacturers in China, but the scale is small. The production means of the key manufacturers and the production level of the general connectors are comparable with those in foreign countries.

The current problem:

The scale is too small.

The concept of market competition did not conform to the development of The Times , the market has already appeared below the cost of sales, there are other unfair competition.

The poor sense of globalization cannot meet the needs of the new economic times.

Digital and e-commerce management lags behind.

Colleges and universities do not have RF connector major, resulting in a shortage of professionals.

The influx of foreign capital and local production.

Precision connector, table patch connector technology is backward.

The problem of passive intermodulation has not attracted enough attention.



Development trend:



Since the market is becoming increasingly competitive, various types of connector products have also entered the equipment upgrade competition. As the world’s largest manufacturer of connector products, China has the largest import and export trade in the world.

Rf coaxial connector not only plays a role of bridge, and have the function of signal processing, such as filtering, phase modulation, mixing, attenuation, detection, clipping, functional diversification, can meet the demand of the rf coaxial connector customers.

Dosin hardware electronics is a professional RF connector manufacturer, has been 13 years of rf connector production history, strong technology, products have passed the ISO certification, in line with international environmental requirements, is worthy of the general new old customers trust rf manufacturers. Each of our radiofrequency connector products promises a free warranty for one year.

What do you know about the RF connectors? In this article, Dosin Hardware Electronic will tell you some content of the development trend for the RF connectors. After reading, you will know more deeply.

1. Miniaturization: with the miniaturization of the whole machine system, the volume of RF connectors is smaller and smaller, such as SSMB and MMCX series, which are very small.

2. High frequency: HP of the US has launched RF connectors with frequency of 110GHz as early as several years ago. Domestic general products frequency no more than 40GHz. Soft cable shall not be used more than 10GHz, and a half – rigid cable shall not exceed 20GHz.

3. Multi-function: besides the function of bridge, it has the function of processing signal, such as filtering, phasing, mixing, attenuation, detection, limiting, etc.

4. Low VSWR: meet the requirements of weapon system and precision measurement.

5. Large capacity and high power: large capacity and high power mainly adapt to the development of information superhighway.

6. Surface mounting: it mainly adapt to the development of SMT (surface mount technology), and facilitates the simplification of the layout design of multi-layer printed boards.

More “development trend of the rf connector” , we will update in website and blog gradually. If you need to purchase rf connector products, you can email us at sale@dosinconn.com, there will be a professional to assist you in your purchasing. Dosin Hardware Electronic, which is experienced in RF field with 13 years. All of our products have adopted ISO certification and guarantee free warranty for 12 months. Welcome to contact us freely for anything.
